    ZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet Press

    Ask Lasest Price
    Brand Name : Tianfeng
    Model Number : ZPW-4-4
    Certification : CE/ISO
    Price : Welcome to consult
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 units/month
    Delivery Time : 45 working days
    • Product Details
    • Company Profile

    ZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet Press


    pharmaceutical pill press machine ZPW-4-4 ZPW-4-2 herbal cube making machine with one ordinary mold

    Main application:
    This machine is dedicated for manufacturing military and civilian hard stacks. The manufacturing process for hard stack is subdivided into five sections, biscuit forming, flour applying, mixing, pressing and packing. In the manufacturing course, biscuit compressor is the key device for pressing.

    Features:

    1. The machine is composed of several parts such as mechanical structure, hydraulic system, electric-driven structure and electronic control part . It is equipped with stainless steel hopper and feeding track.

    2. Except feeding,the machine automatically operates in an unattended way.

    3. Many machine can be connected by conveyor lines to form a unit for automatic running.

    4. If equipped with an automatic feeding part, it can realize full-automatic unattended operation. Manual feeding, automatic pressing,automatic dischargeing, four-station running and four-mold pressing
    5.Manual loading, automatic pressing and discharging Four-station running and double-module pressing


    Technical Parameters of Rotary Tablet Press

    TYPEZPW4-4ZPW4-2
    Max. Compression Pressure180-250180-250
    Max. Dia. of Tablet(mm)According to customer’s requirementAccording to customer’s requirement
    Max. Filling Depth (mm)40 (Adjustable)40 (Adjustable)
    Max. Thickness of Tablet(mm)10-3010-30
    Maximum Working Diameter (mm)1030750
    Turret Speed(r/min)78
    Production Capacity(pc/h)67203840
    Motor(Kw)7.5-11KW7KW
    Overall Size(mm)1750*1200*18101240*920*1710
    Net Weight(Kg)3000200

    ZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet Press

    ZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet PressZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet PressZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet Press

    Packaging & Shipping

    ZPW-4-4 ZPW-4-2 Automatic Tablet Compression Machine 7680 Pieces/Hour Cube Tablet Press

    Export standard plywood package are supplied with well packed. We can make the packages according to customer's request. Sea packages or Air packages are both available.

    Usually shipped pharmaceutical pill press machine ZPW4-2 ZPW-4-4 by sea.

    Our Services

    One station service to make sure our customer get good products and good service.

    (1) Professional advice and rich experience help to choose machine.

    (2) Warranty time: All machines are guaranteed for one year.

    (3) Any problem: If you have any questions or any demands, we will reply you within 24 hours

    except the special reasons once you enquiry us.

    (4) Additives: installation book, Manual book, tool box will be sent with machine.

    Product Quality

    All products are guaranteed for one year, if any problems happen in guarantee period, our company will maintain for free.

    Spare Part Replacement

    First ordinary mold for free, discount if more order. Send one stainless steel dust collector for free.

    Technical Service

    We can provide design, installation and debugging services or remote maintenance teaching.

    Delivery The Cargo To Nearest Port

    We will arrange the shipment and delivery the cargo to your nearest port, save time and cost.

    Detail Product Information

    Provide picture, video, instruction and product brochure.

    Reply Timely

    24 hours hot line ,we will reply email within 12 hours.


    FAQ

    Q: Are you trading company or manufacturer ?

    We are factory, all machines are made by ourselves, and we have our R&D team so we also
    provide customize service and OEM.

    Q: What Machine we make?

    We engaged in making machines for the whole tablets production line and capsule production lines.

    Q:What is your delivery time?

    30 working days for Standard machine, We ship Monday through Saturday.

    Q: Do you provide samples ? Is it free or charged ?

    We can try your powder and send tablets samples for free.If you bear the ship cost.
